Applicable:
This kind of drying oven is proper for drying crude drug, Chinese medicines , pellets, packaging bottle, dehydrated vegetable, fruit, sausage, electric element and so on.
Advantages:
1.CT-C drying oven make oven thermal efficiency improved 3-7% from traditional 35-45%, the highest thermal efficiency is up to 50%.
2.The whole oven we can do stainless steel, carbon steel and contact materials parts stainless steel.
3.The heating source can be electric, steam according to different client's need.
Main data:
Model | CT-C | CT-C-1 | CT-C-2 | CT-C-3 | CT--C-4 |
Machine material | The parts connected with raw materials is 304SS,outside can do carbon steel/stainless | ||||
Every time drying | 30kg | 120kg | 240kg | 360kg | 480kg |
Cycle fan | 0.45kw | 0.45kw | 0.45kw | 0.45kw | 3kw |
Drainage fan | 0.55kw | 0.55kw | 0.75kw | 0.75kw | 0.75kw |
Heating power | 1kw | 15kw | 30kw | 37kw | 45kw |
Steam consumption | 5kg/h | 18kg/h | 36kg/h | 54kg/h | 72kg/h |
Radiator area | 5m2 | 20m2 | 40m2 | 80m2 | 100m2 |
Air volume | 3450m3/h | 3450m3/h | 6900m3/h | 10350m3/h | 13800m3/h |
Baking tray | 8pcs | 48pcs | 96pcs | 144pcs | 192pcs |
Baking car | 1pc | 2pcs | 4pcs | 6pcs | 8pcs |
Size(mm) | 1460×1000×1750 | 2300×1200×3200 | 2300×2200×3200 | 2300×3200×2000 | 4460x2200x2290 |
