Application:
1.CF system grinder is mainly used to grind chemical industry, medicine, food, condiment, resin powder, etc different kinds of materials.
2.By means of relative motion between movable and fixed fluted discs, material is crushed through impact and friction of teeth and impact among material.
3.The whole machine are designed according to “GMP” standard, the whole machine are made of stainless steel, with simple structure, high productivity, easy clean, it’s a perfect and multi function crushing equipment.
Main data:
Model | CF-20B | CF-30B | CF-40B |
Capacity(kg/h) | 60-150 | 100-300 | 160-800 |
Main shaft speed(r/min) | 5200 | 4200 | 4200 |
Crushing mesh(mesh) | 60-150 | 60-120 | 60-120 |
Power(kw) | 3.0 | 5.5 | 7.5 |
Size(mm) | 580x460x1030 | 750x600x1280 | 780x700x1400 |
Weight(kg) | 100 | 200 | 280 |
